Specialists in Robotics and Motion
925/735-0654

We are a sales agency with a highly technical bent.
We serve the motion control needs of northern California and western Nevada.
Stage Link

ABTech Incorporated Web site
Air Bearing Products and Systems

    ABTech offers systems based upon any of several precision bearing technologies. Air bearings manufactured by ABTech include both orifice and porous technologies. They also use mechanical ball bearings and oil hydrostatic bearings where appropriate. Supporting products include controllers, gage stands, and air filter/regulator units. ABTech is an excellent choice for turnkey systems or subsystems.

Precision system solutions
  • High speed rotary spindles
  • Linear slides
  • Rotary positioning stages
  • Tilt/center worktables
  • Gage setting masters


Airex Corporation Web site
Custom rotary motors, Specialty motors

Linear Motors:
*    Exceptional consistency in manufacturing, resulting in minimal force ripple... Greater force constant for a given cross section due to more efficient use of the copper...Better heat dissipation due to a patented technique for heat conduction...Options available for water cooling...Force constants up to 56 #/amp.
Ultra Low-Cogging Brushless Rotary Motors:
*    Exceptionally high peak torque...Toothless stator... Fully molded windings...Thermally conductive design with internal thermistor & case thermostat
Non-Commutated DC Linear motors:
*    Moving coil or moving magnet...Ultra high speed and small size.


Magmotor Corporation Web site
Standard motors, Specialty motors, Magnetic Levitation

Standard and Specialty Motors:
*    A division of Satcon, MagMotor offers a broad range of brush and brushless servomotors, custom designed motors, frameless motors, motor controllers, and custom/specialty DC motor products, including multi-axis stage devices.  MagMotor products are known for their cost effectiveness without sacrificing reliability

Magnetic Levitation Motor systems:
*    Very newly perfected, magnetic levitation technology permits motor operation in which there is no contact between moving parts during operation.  The moving components are suspended in space by magnetic fields.  Friction and internal heat generation is essentially zero.  Equally important is the fact that the armature no longer requires a mounting shaft, so components can be rotated within a chamber without penetrating the chamber to accommodate the shaft.  The object you wish to turn (or its mounting platform) is built right into the armature.  Speeds vary from less than 10 RPM to over 50,000 RPM.  MagMotor provides the controls.


Opti-Cal Web site
Precision linear position sensors

The Micro Path Encoder series laser based linear encoders operate in reflection.  They use point source diffraction from a movable scale and a hologram to sense linear displacement.  This patented technique uses a minimum of optical elements, yet offers many beneficial performance features.  These encoders provide high resolution at a low cost.  There are several configurations of read heads, scales, and signal processing electronics.



Precision MicroDynamics Web site
Servo controllers and amplifiers

Motion Controllers:    All hardware and software required for either centralized or distributed control of stepper and/or servo motors.   Controllers are available in 1, 3, 4 and 8 axis configurations.  Controller products vary from low-cost to high-performance. High performance controllers come with up to 152 I/O all on a single board and achieve servo update rates in the range of 125 nsec for 8 axes at once. New MotionWire modules facilitate high-performance distributed control and data acquisition.
Software:
*    Comprehensive MMI for setup and tuning. PMDI's auto-tune is more accurate than manual tuning.
*    Most applications are developed from an object-oriented drag-and-drop language (Automate) that is programmed similar to Visual Basic.
*    Additional development tools are available for the rare super-critical application that requires writing DSP code. PMDI's open architecture was designed from the ground up to simplify all programming.

Linear Servo Amplifiers:    High performance linear drives for voice coil actuators and dc motors.


Rimtec Corporation Web site
Mechanical and Magnetic Couplings, Torque limiters, Clutches
    Rimtec products come in a wide variety of configurations, but they generally can be generally classified as mechanical or magnetic products.   Magnetic products are generally frictionless.
Mechanical Products
*    Metal Bellows Couplings -- Maximum stiffness and reliability.  Available with collet, expanding, or taper clamps.
*    Servo Insert Couplings-- Low cost, electrical isolation, and dampening with zero backlash.
*    Torque Limiters and Torque Limiting Couplings -- For safety release.
Magnetics Products
*    Coupling -- Couple rotating magnetic energy through glass, vacuum, or pressure boundary without penetrating the enclosure.
*    Torque Limiters and Torque Limiting Couplings -- Safety release with no mechanical wear.
*    Servo Clutches -- Hysteresis type maintains smooth and constant torque during overload.  Synchronous type disengages during overload transmitting little or no torque.

New Concept in Positioning

We are quoting positioning systems based upon a unique newly-patented concept.

Stage page
          This positioning system can be manufactured to any level of accuracy from belt-drive accuracy to laser servo accuracy.
      Highest accuracies achievable are achievable with this new technology, yet construction is much simpler and manufacturing tolerances much less critical than competing technologies.  There are many advantages over familiar technologies:
  • Higher accuracy for a given cost
  • Lower cost for a given accuracy
  • Higher speed
  • Lower profile
  • Vacuum compatibility
For detailed information, Click here
